To make your stay as comfortable and easy going as possible, we have collated handy User Guides for our appliances.

eReflex Trento Suite Electric Fire

Dishwasher

  1. Once you have loaded it with crockery, press the ON/OFF button (1st left)
  2. The Eco 50o programme display flashes.
  3. This programme remains selected unless another programme is selected, by pressing the <  or  > buttons.
  4. Once you have selected your required programme, press the START button (1st right), close the door and the programme starts running.
  5. This is indicated by a light which shines from the bottom of the door onto the kitchen floor, immediately below the cabinet.

Washer Dryer

Wash

  1. Push the door closed until you hear a locking sound.
  2. The detergent drawer is composed of three compartments: the large compartment on the left is for main wash, the middle compartment is for softener and the smaller right side compartment is for prewash.
  3. If you are using a detergent pod or dispensing ball, please place these directly among the laundry in the machine. Remember to remove a dispensing ball if using the dryer function.
  4. Remember to remove these if using the dryer function.
  5. Switch the machine on by pressing the button top right of the control panel.
  6. Select the desired washing programme by using the programme selection knob to the left of the control panel.
  7. Whenever a new programme is selected, the machine will automatically show the recommended temperature and spin speed.
  8. To alter the temperature selection, press the button on the left of the panel. To alter the spin speed, press the second from left button. You will see the lights in the illuminated panel above the buttons indicate the temperature and the spin speed.
  9. Press the Start/Pause button to start your wash.

Dry

  1. Selection for drying: When a new programme is selected, press the Auxillary Function Selection button to adjust the drying option that is suitable for the selected washing programme (buttons 3 to 5 from left on control panel) The 6th from left button can be used the adjust the drying level.
  2. Your selections will be illuminated in the Drying Programme lights above the buttons.

Child Lock

  1. To activate or deactivate the child lock, switch the machine on by pressing the ON/OFF button (top right of control panel).
  • Press and hold the 4th and 5th buttons from the left of the control panel for 3 seconds.

After the countdown, as “Child Lock 3-2-1” on the display is over, “Child Lock Enabled” appears on the display. To deactivate the child lock press and hold the 4th and 5th buttons from the left of the control panel for three seconds. After the countdown as “Child Lock 3-2-1” on the display is over, “Child Lock Enabled” is turned off the display.

Fridge Freezer

  1. The coldest zone is between the arrow stamped on the side of the interior of the fridge and the shelf underneath. It is recommended that perishable foods such as fish and meat are stored here.
  2. The warmest zone is at the very top of the door. Hard cheese and butter can be best stored here.
  3. The vegetable container is recommended for storing fruit, vegetables and salads. You can use the humidity controller to reduce condensation.
  4. If storing mainly fruit, set lower air humidity, or if mainly vegetables or a mix of goods, set higher air humidity.
  5. The freezer compartment is suitable for storing frozen food, making ice cubes and freezing food.

Hob

Operation

  1. Switching the hob on is done by pressing the main switch, which is shown on the first left position at the bottom of the control panel. An audible signal sounds.
  2. The indicator next to the main switch and the hotplate indicators light up and the hob is ready to use.
  3. To switch off: Touch the main switch symbol until the indicator goes out. All hotplates are switched off. Please note: residual heat indicator remains lit until the hotplates have cooled down sufficiently.
  4. Setting a hotplate is done by using the + and – indicators, with 1 being the lowest setting and 9 the highest. Every heat setting has an intermediate setting which is marked with a dot.
  5. Select the hotplate by pressing the circle symbol for the relevant hotplate on the control panel. Touch the + or – symbols within 10 seconds to the required heat setting.
  6. To change the heat setting, touch the required hotplate symbol and then + or – until the required heat setting appears.  Touching the – until 0 appears will switch off the hotplate.
  7. Some things to note:
    1. If no pan has been placed on the hotplate, the selected power level flashes. After a certain time has elapsed, the hotplate switches off.
    1. If a pan has been placed on the hotplate before switching on the hob, it will be detected within 20 seconds of pressing the main switch and the hotplate will be selected automatically. Once detected, select the power level within the next 20 seconds or the hotplate will switch off. If more than one pan is placed on the hob, only one will be detected with switching it on.

Child Lock

You can use the childproof lock to prevent children from switching on the hob. To activate or deactivate the childproof lock, the hob must be switched off. To activate, touch the key symbol (2nd left on control panel), for approximately 4 seconds. The indicator next to the key symbol lights up for 10 seconds. The hob is locked. To deactivate, touch the key symbol for approximately 4 seconds. The lock is released.

Oven

Switching the appliance on and off:

Use the function selector to switch the appliance on or off and setting the heating function. Turning the function selector to any position other than the “Off” position switches on the appliance. To switch off the appliance, always turn the function selector to the “Off” position.

Setting the temperature:

Use the temperature selector to set the temperature or grill setting. The appliance will start to heat after a few seconds.

Time-setting options

There are different time-setting options:

Timer – works like an egg timer. It runs independently of the appliance when it is heating and of other time-setting options and does not affect the appliance.

Cooking time – Once the set cooking time has elapsed, the appliance automatically stops heating.

End time – Enter a cooking time and the required end time. The appliance starts up automatically so that it finishes cooking at the required time.

Time – Set the time, e.g. after a power cut, or change it e.g. from summer to winter time.

An audible signal sounds once the cooking time or timer duration has elapsed. You can cancel the audible signal early by pressing the clock button.

Setting the timer

The timer can be set when the appliance is switched on or off. It has its own audible signal so that you can tell whether it is the timer duration or a cooking time that has elapsed. If the set timer duration is the duration for which you want to cook your food, use the cooking time. The appliance then switches off automatically.

  1. Press the clock button repeatedly until the bell symbol is selected.
  2. Use the < and > buttons to set the timer duration. Default value for the < button is 5 minutes. Default value for > button is 10 minutes. The setting is applied automatically. The timer duration starts to count down after a few seconds. When the set time has elapsed, a signal sounds. To end the timer, press the clock button.

Setting the cooking time

Once the set cooking time has elapsed, the appliance switches off automatically. The function can only be used in combination with a type of heating.

  1. Set the type of heating and temperature.
  2. Press the clock button repeatedly until the symbol |→|is selected.
  3. Use the < and > buttons to set the cooking time. The setting is applied automatically. The appliance starts heating after a few seconds. The duration counts down in the display.

Once the cooking time has elapsed, an audible signal sounds and the appliance brings the operating mode to an end automatically. To switch off, turn the function selector back to the “Off” position.

Setting the end time

You can delay the time at which cooking is due to finish. You can, for example, put your food in the cooking compartment in the morning and set the cooking time so that it is ready at lunch time. Do not adjust the end time once the appliance is already in operation as this will result in unsatisfactory cooking results.

  1. Place the food onto the appropriate accessory in the cooking compartment and close the appliance door.
  2. Set the type of heating and temperature.
  3. Press the clock button repeatedly until the |→| symbol is selected.
  4. Use the < and > buttons to set the cooking time.
  5. Press the clock button repeatedly until the →| symbol is selected.
  6. Use the < and > buttons to set the end time. The appliance applies the settings after a few seconds. The end time is shown in the display. Once the appliance starts, the time begins counting down.

As soon as the end time has been reached, an audible signal sounds and the appliance ends the operation automatically. To switch off, turn the function selector back to the “Off” position.

Checking, changing or deleting settings

  1. Press the clock button repeatedly until the appropriate symbol is selected.
  2. If required, use the < or > button to change the setting. To delete a time-setting option, set 00:00. The setting is applied automatically.

Childproof lock

Your appliance is equipped with a childproof lock. The control panel is locked so that the appliance cannot be switched on. To switch it on, the automatic childproof lock must be interrupted. After the appliance operation, the control panel is locked automatically. To set or interrupt the automatic childproof lock, the function selector must be in the “Off” position.

Ensure that the childproof lock function is set in the basic settings.

  1. Press and hold the clock button for approximately four seconds.

c0 0 or c0 1 appears in the display.

  1. Use the < or > button to change the setting if necessary.

C0 0 = Child-proof lock deactivated

C0 1 = Childproof lock activated

  1. To confirm, press and hold the clock button again for approximately four seconds. The basic setting is applied.

Cancelling

  1. Press and hold the clock button until the key symbol goes out in the display.
  2. Set the type of heating and temperature.

As soon as the appliance is switched off, the automatic childproof lock is reactivated.

Microwave & Oven

To switch the oven on or off, touch the ON/OFF button which is the first symbol on the bottom left of the control panel. You are taken directly to the “Types of heating” menu. Use the < or > button to select the type of heating and use the v button to navigate to the next line. Use the <  > buttons to select the temperature. The oven suggests a temperature or setting for each type of heating. You can accept this value or change it. When a type of heating has been started, the run time is displayed. The run time counts upwards during the operation. You can therefore check how long the operation has been running.

To change or cancel an appliance operation, touch the symbol on the first right bottom side of the panel. If you wish to change the operation, use the up and down arrow head symbols to navigate to the line for the setting that should be changed. Use the < or > symbols  to change the setting. Touch the symbol on the first right bottom side of the panel to start the changed operation.

The oven has three time-setting options:

Timer – the timer functions like an egg timer. The appliance does not switch on and off automatically.

Cooking time – Once the set cooking time has elapsed, the appliance switches off automatically.

Ready at – The appliance switches on automatically, and once the set cooking time has elapsed and the end of time has passed, it switches off automatically.

Please note, if you have set a time-setting option, the time interval increases if you set a higher value. Example: You can set a cooking time of up to one hour in one-minute increments; for cooking times over one hour, you can set a cooking time in five minute increments.

To show or hide the time-setting options, touch the symbol that looks like a clock face. After a particular length of time, the time-setting options that are shown are automatically hidden. If you have already set a cooking time, it will be applied.

Setting the timer:

The timer can be set when the appliance is switched on or off.

  1. Touch the clock button. The time-setting options are shown on the display.
  2. Select the cooking time using the > button.  When the appliance is switched on, us the up/down arrow head button to navigate to the Timer, (symbolised by a bell) and then select the cooking time using the > button.
  3. Touch the clock button to start the timer. The bell symbol appears on the display. The timer counts down. As soon as the set time has elapsed, a signal sounds. To cancel the signal tone, touch the clock button.

Setting the cooking time:

Once the set cooking time has elapsed, the appliance switches of automatically. The function can only be used in combination with a type of heating.

  1. Touch the ON/OFF button (first symbol on bottom left of panel).
  2. Set the type of heating and temperature.
  3. Touch the clock symbol touch button. The time-setting options are shown in the display.
  4. Use the <  or > button to set the cooking time.
  5. Touch the symbol on the first right bottom side of the panel to start the changed operation. As soon as the cooking time has elapsed, an audible signal sounds and the appliance ends the operation automatically. Touch the clock symbol to end the audible signal.

Start delay – “Ready at”

The appliance switches on automatically and switches off at the pre-set end time. To do this, set the cooking time and determine the end time for the operation. The start delay can only be used in combination with a type of heating.

  1. Slide food in to the cooking compartment and close the door.
  2. Touch the ON/OFF button (first symbol on bottom left of panel).
  3. Set the type of heating and temperature.
  4. Touch the clock symbol. The time-setting options are shown on the display.
  5. Select the cooking time using the > button.
  6. Use the down pointing arrow button to navigate to the “Ready at” line
  7. Select the end time using the > button.
  8. Touch the symbol on the first right bottom side o the panel to set. The appliance waits until the appropriate time to start the operation. As soon as the end time has passed, a signal sounds and the appliance stops the operation automatically. To cancel the signal tone, touch the clock touch button.

Childproof lock

The oven is equipped with a childproof lock. It has two different locks: Automatic childproof lock; and a One-time childproof lock.

Automatic childproof lock – Activating

  1. Touch the ON/OFF touch button.
  2. Touch the house symbol on the 2nd left.
  3. Use the < or > button to select “MyProfile”.
  4. Use the down pointing arrowhead button to navigate to the next line.
  5. Use the < or > button to select “Automatic childproof lock”.
  6. Use the down pointing arrowhead to navigate to the bottom line.
  7. Use the > button to select “Activated”.
  8. Touch the house symbol touch button.
  9. Use the down pointing button to navigate to the next line to save the setting. The “Automatic childproof lock” is activated. The key symbol appears on the display after switching off the appliance.

Cancelling

  1. Press and hold the clock touch button until “Childproof lock deactivated” appears on the display.
  2. Touch the ON/OFF touch button.
  3. Switch on the required.

Deactivating

  1. Press and hold the clock touch button until “Childproof lock deactivated” appears on the display.
  2. Touch the ON/OFF touch button.
  3. Touch the house symbol.
  4. Use the < or > button to select “MyProfile”.
  5. Use the down arrow button to navigate to the next line.
  6. Use the < or > button to select “Automatic childproof lock”.
  7. Use the down pointing arrowhead button to navigate to the next line.
  8. Use the < button to select “Deactivated”.
  9. Touch the house symbol button.
  10. Use the down pointing arrowhead button to navigate to the next line to save the setting. The “Automatic childproof lock” is deactivated.
  11. Touch the ON/OFF button.

One-time childproof lock

The control panel is locked so that the appliance cannot be switched on. To switch it on, the one-time childproof lock must be deactivated. After the appliance is switched off, the control panel is no longer locked.

Activating and deactivating

1.       Press and hold the clock touch button until “Childproof lock activated” appears on the display. The childproof lock is activated.

2.       Press and hold the clock touch button until “Childproof lock deactivated” appears on the display. The childproof lock is deactivated.

Microwave

Setting the microwave

To achieve optimum results with the microwave, always insert the wire rack at shelf position 1.

1. Touch the ON/OFF touch button to switch on the appliance.

2. Touch the house symbol touch button. The main menu appears.

3. Use the < or > button to select “Microwave”

4. Use the down arrowhead symbol button to open the microwave menu. A microwave output setting and cooking time are suggested.

5. Use the < or > button to set the require microwave output setting.

6. Use the down arrowhead symbol button to navigate to the next line.

7. Use the < or > button to set the required cooking time.

8. Touch the button on the first right to start the appliance operation.

WARNING! RISK OF BURNS!

Accessible parts become very hot when in operation.

At the highest settings in the microwave only mode, the drying function will automatically switch on an additional heating element to heat the cooking compartment. Never touch the inside surfaces of the cooking compartment or the heating elements while they are hot. Keep children at a safe distance.

Changing the cooking time

You can change the cooking time at any time during operation by touching the <  or  > touch button.

Changing the microwave output setting

Touch the button on the first right of the control panel and reset the microwave output setting and cooking time.

Touch the button the first right of the control panel to start the appliance operation.

The cooking time has elapsed

As soon as the end time has been reached, an audible signal sounds and the appliance ends the microwave operation automatically. “Finished” appears on the display.

Touch the clock symbol touch button to stop the audible signal.

If you want to set a new cooking time, touch the button on the first right to start the appliance operation.

Setting the microwave to combi-mode

1. Touch the ON/OFF touch button to switch on the appliance.

2. Touch the house button. The main menu appears.

3. Use the < or > button to select “Microwave combination operation”.

4. Touch down pointing arrowhead touch button.

5. Use the < or > touch button to set the required type of heating.

6. Use the down pointing arrowhead touch button to navigate to the next line. Set the desired temperature using the < or > button.

7. Use the down pointing arrowhead button to navigate to the next line. Use the < or > button to set the required microwave output setting.

8. Use the down pointing arrowhead button to navigate to the next line. Use the < or > button to set the required cooking time.

9. Touch the button on the first right. The appliance starts the operation. The cooking time counts down on the display. You can change the temperature, microwave output setting and cooking time at any time. To do this, use the up and down arrowhead buttons to navigate to the required field and set the value you want using the < or > button.

The cooking time has elapsed

As soon as the end time has been reached, an audible signal sounds and the appliance ends the microwave operation automatically. “Finished” appears on the display.

Touch the clock touch button to stop the audible signal. To cancel an operation, touch the ON/OFF button.

Extractor

Switch the fan on by pressing the On/Off button on the left of the hood control panel.  The level of extraction can be increased or decreased using the numbered buttons.  The extractor hood light can be switched on and off using the button on the right of the hood control panel. The lighting can be switched on and off independently of the ventilation system.

Bose Sound System

You can access the Bose App on the iPad, located under ‘Entertainment’

To link the Bose Speaker to your own device, turn on your Bluetooth facility and press the button on the speaker with three small dots to activate ‘pairing’.
